Прицеп платформа Goldhofer TN-L6-50/80

For sale: a GOLDHOFER low-loader trailer, type TN-L 6-50/62 (2+4), in a six-axle platform configuration. According to the technical specification, the loading platform extends continuously across all six axles.

Equipment and configuration

- Front tandem-axle assembly with air suspension and raise/lower valve; mounted on a ball turntable and connected to the frame as a steering bogie
- Rear four-axle air-suspension assembly with two rigid axles and two self-steering axles, pneumatic reversing lock, and raise/lower valve
- Chassis frame with two longitudinal centre beams, two outer beams, and cross-members
- Continuous 50 mm-thick spruce timber decking
- Dual-circuit compressed-air braking system with load-sensing control (ALB), ABS, and EBS
- Centralised lubrication system, Bekama make, with grouped lubrication points
- Five pairs of RBS-5 rings in the outer frame; stated pulling force of 10 t per ring
- Yellow warning strips on the sides and orange warning boards at the vehicle corners, as stated in the order confirmation
- Side and rear underrun protection
- Drawbar stated in the documentation as 1,800 mm long, with a Ø 50 mm eye

| Specification | Value |
|---|---:|
| Loading platform | 9,500 × 2,550 mm |
| Loaded loading height, approx. | 1,150 ± 100 mm |
| Overall length | 11,520 mm |
| Speed | 62 km/h |
| Front axle load (2 ×) | 10,000 kg registration value / 11,000 kg technical value |
| Rear axle load (4 ×) | 10,000 kg registration value / 11,000 kg technical value |
| Unladen weight, approx. | 10,000 kg |
| Gross weight — registration value | 60,000 kg |
| Gross weight — technical value | 66,000 kg |
| Payload, approx. — registration value | 50,000 kg |
| Payload, approx. — technical value | 56,000 kg |

This offer is non-binding and is made without warranty or guarantee. The right to prior sale is reserved. A deposit of 10% of the purchase price is required to reserve the vehicle. No reservation or entitlement to availability exists until the payment has been received. The purchase is concluded only upon receipt of payment. The vehicle remains the property of MSG Andert GmbH until paid for in full. Payments are accepted only in euros, without any additional costs to the seller, and only by bank transfer or cash. No cheques are accepted.
